1 x Marl LED Reflector Bulb 209-501-21-38, Slide Base, 5.8mm Lamp, 4.9mm, 12V dc - Marl
£0.00
£5.99
RS 238-7747
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 51A
Marl
LED Reflector Bulb, Slide Base, Red, Single Chip, 5.8 mm Lamp, 4.9mm dia., 12 V dc
- BMUK Part # :-238-7747
- BrandMarl
- Mfr. Part No.209-501-21-38
- You will get 1 Led Reflector Bulb
Product Details
T5.5 Telephone Slide Base Ultra-Bright LEDs, 208 Series
Anode identified by + sign on base
Integral resistor allows direct connection to either 12, 24, 28, 60 or 110Vdc supplies
Note
These LED’s should only be used with suitably rated lampholders. Live parts should be inaccessible when in use. 110Vac LED’s cannot be used with a dropper resistor on 230Vac
MARL, Single Chip LED’s
A series of ultra-bright, sunlight-readable, water-clear LED’s suitable for a variety of applications. Specially manufactured lens provides a very wide viewing angle and high intensity output. Intensities are stated at the following viewing angles for the LED’s: Red 30°, Green 15°, Yellow 16°, Blue 15°, White 45°.
Specifications
Voltage Rating | 12 V dc | |
Light Output Colour | Red | |
Intensity | 11000 mcd | |
Lamp Base | Slide Base | |
Lamp Size | 5.8 mm | |
Chip Type | Single Chip | |
Diameter | 4.9mm | |
Length | 28.8 mm | |
Viewing Angle | 120° | |
Peak Wavelength | 643 nm | |
Current Rating | 20 mA | |
Life Hours | 100000h |
