1 x Maxim MAX4522CPE+, Analogue Switch Quad SPST, 3V, 5V, 9V, 16-Pin - Maxim
£0.00
£5.49
RS 333-290
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 25P
Maxim
Maxim MAX4522CPE+, Analogue Switch Quad SPST, 3 V, 5 V, 9 V, 16-Pin PDIP
- BMUK Part # :-333-290
- BrandMaxim
- Mfr. Part No.MAX4522CPE+
- You will get 1 IC
Product Details
Analogue Switches (Quad), Maxim Integrated
From Maxim Integrated Products, a range of analogue switches and multiplexers to suit a wide variety of purposes.
Analogue Switches, Maxim Integrated
Specifications
Configuration | Quad SPST | |
Package Type | PDIP | |
Mounting Type | Through Hole | |
Typical Single Supply Voltage | 3 V, 5 V, 9 V | |
Switch Type | Analogue | |
Pin Count | 16 | |
Power Supply Type | Dual, Single | |
Input Signal Type | Single Ended | |
Output Signal Type | Single Ended | |
Typical Dual Supply Voltage | ±3 V, ±5 V | |
Minimum Operating Temperature | 0 °C | |
Maximum Operating Temperature | +70 °C | |
Number of Channels per Chip | 4 | |
Height | 4.45mm | |
Width | 7.87mm | |
Dimensions | 19.43 x 7.87 x 4.45mm | |
Length | 19.43mm | |
Maximum Power Dissipation | 842 mW |
