1 x MCP6232-E/MS Microchip, Op Amp, RRIO, 300kHz, 1.8-6V, 8-Pin MSOP - Microchip

roll over the image to zoom in


£0.00
£8.99

RS 724-0494 / VOK FRAG BOX
Earn0
reward points

In stock: 21

Sorry! We're out of stock


    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    VOK OFF FRAG BOX


    Microchip

    • RS Stock No.724-0494
    • BrandMicrochip
    • Mfr Part No.MCP6232-E/MS
    •
    •  Microchip
    •
    • You will get ONE op-amp
    MCP6232-E/MS Microchip, Op Amp, RRIO, 300kHz, 1.8 → 6 V, 8-Pin MSOP
    Product Details

    MCP6231/6232/6234 Operational Amplifiers

    Operational Amplifiers, Microchip

    Specifications
    Maximum Operating Temperature
    +125 °C
    Number of Channels per Chip
    2
    Length
    3mm
    Typical Single Supply Voltage
    1.8 → 6 V
    Typical Slew Rate
    0.15V/µs
    Typical Voltage Gain
    110 dB
    Brand
    Microchip
    Power Supply Type
    Single
    Package Type
    MSOP
    Mounting Type
    Surface Mount
    Minimum Operating Temperature
    -40 °C
    Width
    3mm
    Typical Input Voltage Noise Density
    52nV/√Hz
    Rail to Rail
    Rail to Rail Input/Output
    Height
    0.95mm
    Pin Count
    8
    Dimensions
    3 x 3 x 0.95mm
    Typical Gain Bandwidth Product
    300kHz
    Amplifier Type
    General Purpose
