1 x Panasonic PAN1555 Bluetooth Module 2.0, Arduino Raspberry Pi PIC Project - Panasonic

roll over the image to zoom in


£0.00
£4.99

RS 759-5356 x 1
Earn0
reward points

In stock: 170

Sorry! We're out of stock


    Unit Quantity:
    1
    Unit Type:
    Unit


    Panasonic


    • BMUK Part # :-759-5356
    • BrandPanasonic
    • Mfr. Part No.ENW89815A4KF
    •
    • You will get ONE Bluetooth Chip in Antistatic Packing
    Panasonic



    Panasonic ENW89815A4KF Bluetooth Chip 2.0





    Product Details

    Modem Modules 3.0

    Bluetooth system solutions enabling integrated Bluetooth connection for your product. These modules utilise the simple AT command set for ease of design via the UART or USB peripheral interface.


    General


    Supported Profiles: RFCOMM, SPP device A and B
    Complete Bluetooth 3.0 + EDR solution
    Ultra low power design
    No external components except antenna where not included required
    On-module voltage regulator. External supply 3.0-3.6V
    Reference clock included
    Low power clock from internal oscillator or external low power clock
    High sensitivity design (-86 dBm typ.)


    Interfaces


    3.25 MBaud UART, USB, I2C and SPI Interface
    18 GPIO’s for individual usage for your embedded software
    3 Channel ADC and 1 Channel DAC
    Cortex-M3 ST32F103 core for embedded profiles or application software
    JTAG for boundary scan and debug


    Cut the Cable ™


    Bluetooth - Panasonic






    Specifications


    Bluetooth ClassClass 2
    Bluetooth Version2.0
    Maximum Output Power+4dBm
    Receiver Sensitivity-86dBm
    Supported Bus InterfacesI2C, PCM, UART
    Supported I/O InterfacesSerial
    Dimensions13.5 x 22.75 x 2.8mm
    Height2.8mm
    Length22.75mm
    Maximum Operating Temperature+85°C
    Minimum Operating Temperature-40°C
    Width13.5mm



    Specification PDF Please CLICK HERE
