1 x Silicon Labs C8051T60x MCU development kit C8051T600DK - Silicon Labs
Silicon Labs
Silicon Labs C8051T60x MCU development kit
- BMUK Part # :-757-0225
- BrandSilicon Labs
- Mfr. Part No.C8051T600DK
- You will get 1 Kit
C8051T600DK Development Kit
The C8051T600DK Development Kit contains everything needed to develop applications with the C8051T600, T601, T602, T603, T604 and T605 microcontrollers
Silicon Labs' development kits include advanced debug features enabling the user to fully develop and integrate hardware and software design
Since the MCU has built in debug capabilities, it can be installed into the end application
This development system is not encumbered with sockets, target cables or "ICE Chips"
The development kit supports the following debug features: Run, halt and single-step, Set hardware breakpoints, Inspect/Modify memory and registers, Download program memory
Also available for purchase separately is a C8051T600 QFN Socket Daughter Board for programming QFN devices
Kit Contents
C8051T600 main boardC8051T600 SOIC socket daughter board for programming SOIC devices
C8051T600 emulation daughter board with C8051F300 installed
C8051T600 QFN10 socket daughter board for programming devices
C8051T600-GS samples (5)
IDE and Product Information CD-ROM, which includes the following:
Silicon Laboratories Integrated Development Environment (IDE)
Evaluation version of Keil 8051 development tools (macro assembler, linker, C-compiler)Source code examples and register definition files
Documentation
Configuration Wizard
Third Party Tools and Documentation CD-ROM
Wall mounted universal power supply
USB debug adapter
USB cable
8051 Microcontrollers, Silicon Labs
Classification | Development Kit | |
Technology | 8 bit |
TE Connectivity Black Heat Shrink Tubing, 9.5mm, 2:1, 10m Length
DR-25 Heat shrink Tubing (Shrink Ratio 2:1)
Robust and flexible heat shrink tubing. It protects wires and cables against damage from chemicals, abrasion, and fluids. The tubing is ideal for use in high temperature environments as it has been specially designed for long term heat resistance and is flame retardant.
Features and Benefits
• Offers excellent protection and insulation
• Provides strain relief
• Performs well under long-term heat exposure
• The tubing is printed with the product description and size
• Shrink ratio of 2:1
• Use with System 25 range products for a complete cable harness system
Standards
VG95343 Part 5 Type D, VDE 0341/Pt 9005, AMS-DTL-23053/16, BS36-198 Part 3 10A.
High Temperature
Sleeve Diameter | 9.5mm | |
Shrunk Diameter | 4.8mm | |
Colour | Black | |
Sleeve Type | Heat Shrink | |
Shrink Ratio | 2:1 | |
Sleeve Length | 10m | |
Material | Elastomer | |
Minimum Operating Temperature | -75°C | |
Maximum Operating Temperature | +150°C | |
Dielectric Strength | 8kV/mm |
Microchip MCP7940M-I/SN Real Time Clock — Calendar, NV SRAM, 64B RAM 8-Pin SOIC
MCP7940M I²C Real-Time Clock/Calendars
The Microchip MCP7940M is Real-Time Clock Calendar (RTCC) that supports I²C communications. The MCP7940M includes a digital trimming circuit for accuracy which can compensate for crystal tolerance and temperature.
The MCP7940M features a multi-functional output that can be configured as an alarm output, to output a selectable frequency square wave or as a general purpose output.
Features
2-Wire Serial Interface, I²C™ Compatible: I²C clock rate up to 400 kHzOn-Chip Digital Trimming/Calibration: ±1 ppm resolution, ±129 ppm range
Tracks Hours, Minutes, Seconds, Day of Week, Day, Month and Year
Leap Year Compensated to 2399
12/24 Hour Modes
Oscillator for 32.768 kHz Crystals: Optimised for 6-9 pF crystals
Dual Programmable Alarms
Versatile Output Pin
Wide Operating Voltage Range: 1.8V to 5.5V
Low Typical Timekeeping Current: 1.2μA at 3.3V
Real Time Clock Peripherals - Microchip
Functions | Calendar, NV SRAM | |
Date Format | DW:DM:M:Y | |
Time Format | HH:MM:SS | |
User RAM | 64B | |
Bus Type | Serial-I2C | |
Mounting Type | Surface Mount | |
Package Type | SOIC | |
Pin Count | 8 | |
Dimensions | 4.9 x 3.9 x 1.25mm | |
Length | 4.9mm | |
Width | 3.9mm | |
Height | 1.25mm | |
Maximum Operating Supply Voltage | 5.5 V | |
Minimum Operating Supply Voltage | 1.8 V | |
Maximum Operating Temperature | +85 °C | |
Minimum Operating Temperature | -40 °C |
