1 x STMicro STV240N75F3 N-channel MOSFET, 240A, 75V STripFET F3, 10-Pin - STMicroelectronics
£0.00
£10.99
RS 761-0253
Unit Quantity:
1
Unit Type:
Unit
Location:
ES-5L
STMicroelectronics
STMicroelectronics STV240N75F3 N-channel MOSFET, 240 A, 75 V STripFET F3, 10-Pin PowerSO
- BMUK Part # :-761-0253
- BrandSTMicroelectronics
- Mfr Part No.STV240N75F3
- You will get 1 Transistor
Product Details
N-Channel STripFET™ F3, STMicroelectronics
STripFET™ MOSFETs with a wide breakdown voltage range offer ultra-low gate charge and low on-resistance.
MOSFET Transistors, STMicroelectronics
Specifications
Maximum Operating Temperature
+175 °C
Number of Elements per Chip
1
Length
9.6mm
Transistor Configuration
Single
Typical Turn-On Delay Time
25 ns
Brand
STMicroelectronics
Typical Turn-Off Delay Time
100 ns
Maximum Continuous Drain Current
240 A
Package Type
PowerSO
Maximum Power Dissipation
300 W
Series
STripFET F3
Mounting Type
Surface Mount
Minimum Operating Temperature
-55 °C
Width
9.5mm
Maximum Gate Threshold Voltage
4V
Height
3.75mm
Minimum Gate Threshold Voltage
2V
Maximum Drain Source Resistance
2.6 mΩ
Maximum Drain Source Voltage
75 V
Pin Count
10
Dimensions
9.6 x 9.5 x 3.75mm
Category
Power MOSFET
Typical Gate Charge @ Vgs
85 nC @ 10 V
Transistor Material
Si
Channel Mode
Enhancement
Typical Input Capacitance @ Vds
6800 pF @ 25 V
Channel Type
N
Maximum Gate Source Voltage
-20 V, +20 V
