1 x STMicroelectronics STW75NF30 N-Channel MOSFET 60A 300V STripFET F3 TO-247 - STMicroelectronics

roll over the image to zoom in


£0.00
£7.40

RS 168-7586
Earn0
reward points

In stock: 355

Sorry! We're out of stock


    Unit Quantity:
    1
    Unit Type:
    Unit
    Model:
    STW75NF30
    Location:
    TS BRA-14D


    STMicroelectronics

    STW75NF30 N-Channel MOSFET, 60 A, 300 V STripFET F3, 3-Pin TO-247 STMicroelectronics


    • BMUK Stock No.168-7586
    • BrandSTMicroelectronics
    • Mfr Part No.STW75NF30
    •
    • You will get ONE mosfet
    •
    •







    Product Details

    N-Channel STripFET™ F3, STMicroelectronics

    STripFET™ MOSFETs with a wide breakdown voltage range offer ultra-low gate charge and low on-resistance.




    MOSFET Transistors, STMicroelectronics

    Specifications

    Maximum Operating Temperature
    +150 °C
    Maximum Continuous Drain Current
    60 A
    Package Type
    TO-247
    Maximum Power Dissipation
    320 W
    Mounting Type
    Through Hole
    Width
    5.15mm
    Height
    20.15mm
    Dimensions
    15.75 x 5.15 x 20.15mm
    Transistor Material
    Si
    Number of Elements per Chip
    1
    Length
    15.75mm
    Transistor Configuration
    Single
    Typical Turn-On Delay Time
    115 ns
    Brand
    STMicroelectronics
    Typical Turn-Off Delay Time
    141 ns
    Series
    STripFET F3
    Minimum Operating Temperature
    -55 °C
    Maximum Gate Threshold Voltage
    4V
    Minimum Gate Threshold Voltage
    2V
    Maximum Drain Source Resistance
    45 mΩ
    Maximum Drain Source Voltage
    300 V
    Pin Count
    3
    Category
    Power MOSFET
    Typical Gate Charge @ Vgs
    164 nC @ 10 V
    Channel Mode
    Enhancement
    Typical Input Capacitance @ Vds
    5930 pF@ 25 V
    Channel Type
    N
    Maximum Gate Source Voltage
    -20 V, +20 V
    BMUK Part # :-
