1 x TDK-Lambda 50.4W Isolated DC-DC Converter SMD Vin 14.4-36V Vout 24Vdc - TDK-Lambda
TDK-Lambda
TDK-Lambda 50.4W Isolated DC-DC Converter Surface Mount, Voltage in 14.4 → 36 V dc, Voltage out 24V dc
- BMUK Stock No.787-4439
- BrandTDK-Lambda
- Mfr Part No.CN50A24-24
- You will get ONE DC-DC Converter
TDK-Lambda CN-A 24VDC Series, 100W 24Vdc Input, Quarter Brick Railway Isolated DC-DC Converters
CN-A 24VDC series, 50/100W 24Vdc input, railway isolated DC-DC converters with a compact pin-out design that uses less PCB space and a wide input voltage range of 14.4 to 36Vdc. These CN-A 24VDC series 50 W and 100W railway isolated DC-DC converters are compliant with the applicable railway standards and are designed for harsh environments, meeting the shock and vibration requirements of IEC61373 Category 1 Class B. True useable power from -40 to +100°C without derating can be provided by these railway isolated DC-DC converters which are base-plate cooled, they can also offer up to 88% efficiency and up to 20A useable output current. Typical uses for these CN-A 24VDC series railway isolated DC-DC power modules include battery powered railway systems such as rolling stock and fixed installations, power plants and customer power supplies
