1 x Texas Instruments CD74HC194PW 4-Stage Shift Register Bi-Directional - Texas Instruments

roll over the image to zoom in


£0.00
£5.95

RS 663-0149
Earn0
reward points

In stock: 100

Sorry! We're out of stock


    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS BRA-2G


    Texas Instruments

    Texas Instruments CD74HC194PW 4-stage Shift Register, Serial/Parallel to Parallel, Bi-Directional, 16-Pin TSSOP


    • BMUK Stock No.663-0149
    • BrandTexas Instruments
    • Mfr Part No.CD74HC194PW
    •
    • You will get ONE shift register








    Product Details

    74HC Family Counters & Shift Registers, Texas Instruments

    Texas Instruments range of Counters and Shift Registers from the 74HC Family of CMOS Logic ICs. The 74HC Family use silicon gate CMOS technology to achieve operating speeds similar to the LSTTL family but with the low power consumption of standard CMOS integrated circuits.

    High-Speed CMOS Logic
    Operating Voltage: 2 to 6 V
    Compatibility: Input CMOS, Output CMOS




    74HC Family







    Specifications

    Maximum Operating Temperature
    +125 °C
    Number Of Elements
    1
    Length
    5mm
    Reset Type
    Asynchronous
    Minimum Operating Supply Voltage
    2 V
    Brand
    Texas Instruments
    Package Type
    TSSOP
    Mounting Type
    Surface Mount
    Minimum Operating Temperature
    -55 °C
    Width
    4.4mm
    Operation Mode
    Serial/Parallel to Parallel
    Logic Family
    HC
    Height
    1.15mm
    Logic Function
    Shift Register
    Number of Stages
    4
    Triggering Type
    Positive Edge
    Maximum Operating Supply Voltage
    6 V
    Pin Count
    16
    Dimensions
    5 x 4.4 x 1.15mm
    Direction Type
    Bi-Directional

    TE Connectivity Black Heat Shrink Tubing, 9.5mm, 2:1, 10m Length






    Product Details

    DR-25 Heat shrink Tubing (Shrink Ratio 2:1)

    Robust and flexible heat shrink tubing. It protects wires and cables against damage from chemicals, abrasion, and fluids. The tubing is ideal for use in high temperature environments as it has been specially designed for long term heat resistance and is flame retardant.


    Features and Benefits
    • Offers excellent protection and insulation
    • Provides strain relief
    • Performs well under long-term heat exposure
    • The tubing is printed with the product description and size
    • Shrink ratio of 2:1
    • Use with System 25 range products for a complete cable harness system

    Standards

    VG95343 Part 5 Type D, VDE 0341/Pt 9005, AMS-DTL-23053/16, BS36-198 Part 3 10A.





    High Temperature



    Add product to Compare


    Specifications

    Not what you’re looking for? Select the attributes you require, then click the button below

    Sleeve Diameter9.5mm

    Shrunk Diameter4.8mm

    ColourBlack

    Sleeve TypeHeat Shrink

    Shrink Ratio2:1

    Sleeve Length10m

    MaterialElastomer

    Minimum Operating Temperature-75°C

    Maximum Operating Temperature+150°C

    Dielectric Strength8kV/mm

    Microchip MCP7940M-I/SN Real Time Clock — Calendar, NV SRAM, 64B RAM 8-Pin SOIC


    • BMUK Part # :-761-7627
    • BrandMicrochip
    • Mfr. Part No.MCP7940M-I/SN





    Product Details

    MCP7940M I²C Real-Time Clock/Calendars

    The Microchip MCP7940M is Real-Time Clock Calendar (RTCC) that supports I²C communications. The MCP7940M includes a digital trimming circuit for accuracy which can compensate for crystal tolerance and temperature.

    The MCP7940M features a multi-functional output that can be configured as an alarm output, to output a selectable frequency square wave or as a general purpose output.



    Features

    2-Wire Serial Interface, I²C™ Compatible: I²C clock rate up to 400 kHz
    On-Chip Digital Trimming/Calibration: ±1 ppm resolution, ±129 ppm range
    Tracks Hours, Minutes, Seconds, Day of Week, Day, Month and Year
    Leap Year Compensated to 2399
    12/24 Hour Modes
    Oscillator for 32.768 kHz Crystals: Optimised for 6-9 pF crystals
    Dual Programmable Alarms
    Versatile Output Pin
    Wide Operating Voltage Range: 1.8V to 5.5V
    Low Typical Timekeeping Current: 1.2μA at 3.3V




    Real Time Clock Peripherals - Microchip



    Add product to Compare


    Specifications

    Not what you’re looking for? Select the attributes you require, then click the button below

    FunctionsCalendar, NV SRAM

    Date FormatDW:DM:M:Y

    Time FormatHH:MM:SS

    User RAM64B

    Bus TypeSerial-I2C

    Mounting TypeSurface Mount

    Package TypeSOIC

    Pin Count8

    Dimensions4.9 x 3.9 x 1.25mm

    Length4.9mm

    Width3.9mm

    Height1.25mm

    Maximum Operating Supply Voltage5.5 V

    Minimum Operating Supply Voltage1.8 V

    Maximum Operating Temperature+85 °C

    Minimum Operating Temperature-40 °C
