1 x TRACOPOWER Isolated DC-DC Converter TEN 10-1210, Vin 9-18V dc, Vout 3.3V dc - TRACOPOWER
TRACOPOWER
TRACOPOWER Isolated DC-DC Converter, Vin 9 → 18 V dc, Vout 3.3V dc, I/O isolation 1500V dc
- BMUK Part # :-242-2395
- BrandTRACOPOWER
- Mfr. Part No.TEN 10-1210
- You will get 1 DC-DC Converter
Traco 10W Regulated Isolated DC-DC Converter - TEN10 Series
10W single/dual output regulated isolated high performance DC-DC converters with a compact low profile package. These DC-DC converters have a high efficiency enabling an operating temperature range of -40°C to +85°C and a built-in EMI filter to EN 5022 class A without external components. Typical applications for these DC-DC converters include battery operated equipment, instrumentation, distributed power architectures in communication and industrial electronics.
Products not recommended for new designs please refer to the alternative at the bottom of the page
Wide 2:1 input range
1.5kVdc input/output isolation, case 1kVdc
Input filter to EN55022 Class A and FCC Level A without external components
Regulated outputs
Continuous short circuit protection
Shielded metal case with insulated base-plate
SMD technology with ceramic chip capacitors
Approvals
UL/cUL
Standards
UL 60950-1, IEC / EN 60950-1
Traco - 10W to 15W
Output Voltage | 3.3V dc | |
Input Voltage Range | 9 → 18 V dc | |
Input Voltage Nominal | 12 V dc | |
Isolation Voltage | 1500V dc | |
Output Current | 2.4A | |
Mounting Type | Through Hole | |
Number of Outputs | 1 | |
Package | 2 x 1 in | |
Efficiency | 72% | |
Minimum Temperature | -40°C | |
Maximum Temperature | +85°C | |
Load Regulation | ±0.5% | |
Line Regulation | ±0.3% | |
Width | 25.4mm | |
Ripple And Noise | 50mV Pk-Pk | |
Series | TEN 10 | |
Weight | 30g | |
Length | 50.8mm | |
Depth | 10.2mm | |
MTBF | 1000000h |
