10 x RS RNYDS5-4 Insulated Crimp Ring Terminal, M4 (#8) Stud, 4mm²-6mm² 12-10AWG - RS Pro

roll over the image to zoom in


£0.00
£5.99

RS 267-3903
Earn0
reward points

In stock: 5

Sorry! We're out of stock


    Unit Quantity:
    10
    Unit Type:
    Unit
    Location:
    ES-12F


    RS Pro

    RS Pro RNYD Series Insulated Crimp Ring Terminal, M4 (#8) Stud Size, 4mm² to 6mm², 12AWG to 10AWG, Yellow


    • BMUK Part # :-267-3903
    • BrandRS Pro
    • Mfr. Part No.RNYDS5-4
    •
    • You will get a pack of 10 Connectors
















    Product Details

    RS Pro Insulated Double Crimp Ring Terminals

    Insulated copper double crimp ring terminals with a copper sleeved double crimp barrel. These insulated crimp ring connectors are colour coded for use with different wire ranges and are available with various stud sizes. For suitable crimp tool see stock number 267-3133.

    Red 0.5 - 1.5 mm²
    Blue 1 - 2.6 mm²
    Yellow 2.5 - 6.5 mm²

    Approvals

    UL Listed; UL Listed for Canada





    RS Pro Range

    Technical Specification
    Temperature rating+70°C
    Body MaterialCopper
    Body PlatingTin
    Specifications


    SeriesRNYD

    Inner Ring Diameter4.3mm

    InsulationInsulated

    Insulation MaterialNylon

    Outer Ring Diameter7.2mm

    Minimum Wire Size mm²4mm²

    Maximum Wire Size mm²6mm²

    Minimum Wire Size AWG12AWG

    Maximum Wire Size AWG10AWG

    Stud SizeM4 (#8)

    ColourYellow

    Contact MaterialCopper

    Thickness1mm

    Overall Length22.7mm


    To view the datasheet please   Click Here
