105 x Panasonic PAN1325A-HCI-70 Bluetooth Module 2.1 - Panasonic

roll over the image to zoom in


£0.00
£102.99

RS 759-5334 LOT 2
Earn0
reward points

In stock: 1

Sorry! We're out of stock


    Unit Quantity:
    105
    Location:
    Reel Variety Box


    Panasonic

    Panasonic PAN1325A-HCI-70 Bluetooth Module 2.1


    • BMUK Part # :- 759-5334
    • BrandPanasonic
    • Mfr. Part No.PAN1325A-HCI-70
    •
    •
    •
    • You will get 105 Bluetooth Modules on a Reel







    Product Details

    PAN1315/25 v2.1 Bluetooth® EDR HCI Module, Panasonic

    The PAN1315/1325 series from Panasonic are Host Controlled Interface (HCI) Bluetooth modules with Enhanced Data Rate (EDR). These modules are based upon the seventh generation CC2560 Bluetooth core integrated circuit from Texas Instruments and are 100% pin compatible with the next generation of Bluetooth Dual Mode Low Energy devices.


    Features


    FCC and IC listed, CE complied
    Dimensions: PAN1325 with antenna 9.0 x 9.5 x 1.8 mm, PAN1315 without antenna 9.0 x 6.5 x 1.8 mm
    Operating Temperature Range: -20°C to +70°C
    Supply Voltage Range: 1.7 - 4.8 V
    Texas Instruments’ CC2560 7th generation Bluetooth controller inside
    Integrates with TI's low-power MSP430 microprocessor
    Profiles: Serial Port Profile (SPP), Health Device Profile (HDP), Audio and others
    Very fast algorithm for both Asynchronous Connection-Less (ACL) and Extended Synchronous Connections (eSCO)
    Supports Extended Range Tx power with 10.5dBm typical output
    Low power scan method and inquiry scans at 1/3rd normal power


    Interfaces


    3.25 MBaud UART with transport layer detection (HCI UART, HCI Three and Four Wire UART)
    PCM/I2S interface for digital audio
    WLAN coexistence interface
    General purpose I/Os with interrupt capabilities




    Bluetooth - Panasonic



    Specifications


    Bluetooth ClassClass 1, Class 2

    Bluetooth Version2.1

    Maximum Output Power+10dBm

    Receiver Sensitivity-93dBm

    Supported Bus InterfacesUART, 3-Wire, 4-Wire

    Supported I/O InterfacesNone

    Dimensions9 x 9.5 x 1.8mm

    Height1.8mm

    Length9.5mm

    Maximum Operating Temperature+70°C

    Minimum Operating Temperature-20°C

    Width9mm
