119 x Panasonic ELJFB Series Type 1812 Wire-wound SMD Inductor 56uH ±5%, 125mA - Panasonic

roll over the image to zoom in


£0.00
£76.99

RS 620-8985
Earn0
reward points

In stock: 1

Sorry! We're out of stock


    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    APR BOX S


    Panasonic

    Panasonic ELJFB Series Type 1812 Wire-wound SMD Inductor 56 μH ±5% Wire-Wound 125mA Idc Q:40


    • BMUK Part # :-620-8985
    • BrandPanasonic
    • Mfr. Part No.ELJFB560JF
    •
    •
    • You will get a pack of 119 Inductors




    Image representative of range



    Product Details

    Panasonic 1812 ELJFB Series Wire Wound Inductors

    General use wire wound and resin moulded chip inductor
    Correspond to Re-flows soldering and flow soldering
    Applications include AV equipment, Wireless communication equipment and general electronic equipment


    SMT 1812 Inductors (Chokes)


    Specifications


    Inductance56 μH

    Maximum DC Current125mA

    Package/Case1812

    Length4.5mm

    Depth3.2mm

    Height3.2mm

    Dimensions4.5 x 3.2 x 3.2mm

    Tolerance±5%

    Maximum DC Resistance4.7Ω

    SeriesELJFB

    Maximum Self Resonant Frequency9MHz

    MouldedYes

    Minimum Operating Temperature-20°C

    Inductor ConstructionWire-Wound

    Maximum Operating Temperature+85°C

    Minimum Quality Factor40


    To view the datasheet please Click Here



    Please visit our shop to see all our other items we have in stock,





    Please call us if you have any questions,





    Many thanks!
