1x STMicro STP6NK50Z N-Channel MOSFET 5.6A 500V MDmesh SuperMESH TO-220 - STMicroelectronics

roll over the image to zoom in


£0.00
£5.99

RS 761-2916
Earn0
reward points

In stock: 70

Sorry! We're out of stock


    Unit Quantity:
    1
    Unit Type:
    Unit
    Model:
    STP6NK50Z
    Location:
    TS BRA-2H


    STMicroelectronics

    STP6NK50Z N-Channel MOSFET Transistor, 5.6 A, 500 V MDmesh, SuperMESH, 3-Pin TO-220 STMicroelectronics


    • BMUK Stock No.761-2916
    • BrandSTMicroelectronics
    • Mfr Part No.STP6NK50Z
    •
    •
    •
    • You will get ONE mosfter








    Product Details

    N-Channel MDmesh™ SuperMESH™, 250V to 650V, STMicroelectronics








    MOSFET Transistors, STMicroelectronics

    Specifications

    Maximum Operating Temperature
    +150 °C
    Number of Elements per Chip
    1
    Length
    10.4mm
    Transistor Configuration
    Single
    Typical Turn-On Delay Time
    12 ns
    Brand
    STMicroelectronics
    Typical Turn-Off Delay Time
    31 ns
    Maximum Continuous Drain Current
    5.6 A
    Package Type
    TO-220
    Maximum Power Dissipation
    90 W
    Series
    MDmesh, SuperMESH
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55 °C
    Width
    4.6mm
    Maximum Gate Threshold Voltage
    4.5V
    Height
    15.75mm
    Minimum Gate Threshold Voltage
    3V
    Maximum Drain Source Resistance
    1.2 Ω
    Maximum Drain Source Voltage
    500 V
    Pin Count
    3
    Dimensions
    10.4 x 4.6 x 15.75mm
    Category
    Power MOSFET
    Typical Gate Charge @ Vgs
    24.6 nC @ 10 V
    Transistor Material
    Si
    Channel Mode
    Enhancement
    Typical Input Capacitance @ Vds
    690 pF @ 25 V
    Channel Type
    N
    Maximum Gate Source Voltage
    -30 V, +30 V
    BMUK Part # :-
