5 x Microchip PIC12C671-04/P 8bit PIC Microcontroller 4MHz 1024 x 14 words 8-Pin - Microchip
£0.00
£19.99
RS 328-1858
Unit Quantity:
5
Unit Type:
Unit
Location:
BRA 9D
Microchip
Microchip PIC12C671-04/P, 8bit PIC Microcontroller, 4MHz, 1024 x 14 words EPROM, 8-Pin PDIP
- BMUK Part # :-328-1858
- BrandMicrochip
- Mfr. Part No.PIC12C671-04/P
- You will get a pack of 5 Microcontrollers
Product Details
PIC12C67x 8-Bit Microcontrollers
The PIC12C range from Microchip are 8-bit CMOS microcontrollers (MCUs) that incorporate Microchip’s PIC® architecture into a low pin count package. Now supplanted by Flash based variants these CMOS devices are still popular in legacy designs. For new applications PIC12F variants should be considered.
These PIC12C67x microcontrollers are based upon Microchip’s mid-range core that includes interrupt capability, a deep hardware stack and 12-bit wide instructions. These MCUs provide up to 2.5 MIPS, up to 3.5 Kbytes program memory and data memory of up to 128 bytes. On board is a RC oscillator with ±1% accuracy.
Features
4 MHz CPU35 Instructions
Interrupt capability
Eight level deep hardware stack
4 MHz precision internal RC oscillator
Five I/O Pins
Four channel, 8-bit Analogue to Digital Converter (ADC)
8-bit real-time timer/counters with 8-Bit programmable prescaler
In-Circuit Serial Programming (ICSP)
PIC12C Microcontrollers
Specifications
Family Name | PIC12C | |
Package Type | PDIP | |
Mounting Type | Through Hole | |
Pin Count | 8 | |
Device Core | PIC | |
Data Bus Width | 8bit | |
Program Memory Size | 1024 x 14 words | |
Maximum Frequency | 4MHz | |
RAM Size | 128 B | |
ADC Channels | 4 | |
Typical Operating Supply Voltage | 3 → 5.5 V | |
Maximum Operating Temperature | +70 °C | |
Instruction Set Architecture | RISC | |
Height | 3.68mm | |
Program Memory Type | EPROM | |
Width | 6.6mm | |
ADCs | 4 x 8 bit | |
Number of ADC Units | 1 | |
Number of Timers | 1 | |
ADC Resolution | 8bit | |
Timer Resolution | 8bit | |
Timers | 1 x 8 bit | |
Dimensions | 9.78 x 6.6 x 3.68mm | |
Length | 9.78mm | |
Minimum Operating Temperature | 0 °C |
