IXYS IXTK46N50L N-channel LINEAR POWER MOSFET Transistor 46A 500V, 3-Pin TO-264 - IXYS

roll over the image to zoom in


£0.00
£39.00

RS 686-7856
Earn0
reward points

In stock: 11

Sorry! We're out of stock


    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TS BRA-3H


    IXYS

     IXYS IXTK46N50L N-channel MOSFET Transistor, 46 A, 500 V, 3-Pin TO-264

    You will get ONE MOSFET Transistor in Anti Static packing

    These are designed for linear use in application like electronic loads, DC/DC converters etc

    IXYS IXTK46N50L N-channel MOSFET Transistor, 46 A, 500 V, 3-Pin TO-264

    Product Details

    N-Channel MOSFETs 43A to 49A

    MOSFETs - N-Channel

    The Metal–Oxide–Semiconductor Field-Effect Transistor or MOSFET is a transistor used for amplifying or switching electronic signals.
    A voltage on the oxide-insulated Gate electrode can induce a conducting channel between the two other contacts called Source and Drain. The channel can be of N-type or P-type.





    Specifications

    CategoryPower MOSFET
    Channel ModeEnhancement
    Channel TypeN
    ConfigurationSingle
    Dimensions19.96 x 5.13 x 26.16mm
    Height26.16mm
    Length19.96mm
    Maximum Continuous Drain Current       46 A
    Maximum Drain Source Resistance0.16 Ω
    Maximum Drain Source Voltage500 V
    Maximum Gate Source Voltage±30 V
    Maximum Operating Temperature+150 °C
    Maximum Power Dissipation700 W
    Minimum Operating Temperature-55 °C
    Mounting TypeThrough Hole
    Number of Elements per Chip1
    Package TypeTO-264
    Pin Count3
    Typical Gate Charge @ Vgs260 nC V @ 15
    Typical Input Capacitance @ Vds7000 pF V @ 25
    Typical Turn-Off Delay Time80 ns
    Typical Turn-On Delay Time40 ns
    Width5.13mm





    For a Specification PDF Please CLICK HERE
