Nano 40X BASIC Microcontroller IC STAMP Electronics Robotics Project Prototype - Basic Micro

roll over the image to zoom in


£0.00
£16.99

B0028
Earn0
reward points

In stock: 41

Sorry! We're out of stock



    Basic Micro

    The Nano 40X is a turbo version of the Nano. The Nano X lets you get the most performance possible from a small BASIC programmable microcontroller. It runs at 20Mhz with an external resonator.

    The Nano is an excellent way to get started with microcontrollers. The BASIC programming environment is free and offers many sample programs along with a free manual.

    Your program is downloaded to the Nano using a simple serial or USB connection to your PC.

    Downloads

  • Nano-40X Data Sheet
  • BMUKIDE Programming Manual

    Features

  • 2x Faster than Nano
  • Low part count
  • Easy to use
  • Volume discounts
  • NO external eeprom required !
  • Ideal for use in products
  • Built-in 14K Program Space
  • 256 Bytes of EEPROM
  • 35 I/O pins
  • Built in Debugger
  • 2 Comparators
  • 2 capture/compare/PWM
  • 2 Enhanced capture/compare/PWM
  • Hardware USART
  • Synchronous serial port
  • 3-wire Serial Peripheral Interface (SPI)
  • IC Interface
  • 14 channel Analog-to-Digital converter
  • 32 Bit Floating Point Math
  • 32 Bit Integer Math
  • Over 33,000 BASIC Instructions Per Second
